橫向小拉桿波紋管膨脹節
橫向小拉桿波紋管膨脹節
橫向小拉桿波紋管膨脹節性能特點：
橫向小拉桿波紋膨脹節由兩段波紋管、中間接管及帶有限位螺母的小拉桿等零件組成，它在吸收橫向位移的同時，還吸收軸向位移。小拉桿不能承受內壓推力，壓力推力必須由管道固定支架承受。補償器采用特殊結構可徹底防止波紋內積粉，根據客戶要求，可制作耐高溫型、耐磨型（耐磨導流筒/耐磨陶瓷）小拉桿波紋管膨脹節。橫向位移是波紋管一端和另外一端縱軸垂直方向上的相對位移。單式波紋管可以有橫向位移，但是位移量是很小的。一個很好的解決方法采取復式波紋管。結果是橫向位移補償量增大并且作用力減小。
公稱通徑DN | 壓力0.6Mpa | 壓力1.0Mpa | 壓力1.6Mpa | 有效面積Acm2 | 焊接短管d×tmm | 總長Lmm | 總量KgF/H | |||
軸向位移/軸向剛度mm/(N/mm) | 橫向位移/橫向剛度mm/(N/mm) | 軸向位移/軸向剛度mm/(N/mm) | 橫向位移/橫向剛度mm/(N/mm) | 軸向位移/軸向剛度mm/(N/mm) | 橫向位移/橫向剛度mm/(N/mm) | |||||
100 | 320/210 | 96/8.0 | 28/252 | 86/9.6 | 26/302 | 78/12 | 154 | 08×4 | 1000 | 30 |
200/2.0 | 180/2.5 | 162/31 | 1500 | 36 | ||||||
306/0.98 | 27/1.1 | 248/1.3 | 2000 | 41 | ||||||
411/0.50 | 370/0.6 | 333/0.75 | 2500 | 47 | ||||||
125 | 33/170 | 83/18 | 31/204 | 78/21.6 | 29/245 | 75/25.9 | 180 | 33×4 | 1000 | 39 |
115/6.8 | 109/8.2 | 103/9.8 | 1500 | 43 | ||||||
198/3.5 | 188/4.2 | 178/5.0 | 2000 | 51 | ||||||
269/1.8 | 255/2.2 | 242/2.6 | 2500 | 62 | ||||||
150 | 32/290 | 65/21 | 30/348 | 61/25.2 | 27/417 | 58/30.2 | 299 | 59×4.5 | 1000 | 42 |
136/5.4 | 129/65 | 122/7.8 | 1500 | 53 | ||||||
107/2.4 | 197/2.9 | 186/3.5 | 2000 | 63 | ||||||
279/1.4 | 265/1.68 | 251/2.1 | 2500 | 74 | ||||||
200 | 48/326 | 72/47 | 43/391 | 68/56.4 | 40/469 | 65/70.5 | 531 | 19×6 | 1000 | 72 |
160/11 | 152/13.2 | 144/16.5 | 1500 | 89 | ||||||
250/5.0 | 273/6.0 | 225/7.5 | 2000 | 106 | ||||||
341/2.8 | 324/3.4 | 291/4.1 | 2500 | 123 | ||||||
250 | 46/400 | 127/20 | 43/480 | 114/25 | 38/576 | 108/30 | 774 | 73×8 | 1000 | 121 |
199/9.0 | 179/10.8 | 170/13.5 | 1500 | 150 | ||||||
271/5.0 | 257/6.0 | 231/7.5 | 2000 | 178 | ||||||
343/3.2 | 325/3.8 | 293/4.6 | 2500 | 206 | ||||||
300 | 59/336 | 134/25 | 56/403 | 127/30 | 50/483 | 121/36 | 1069 | 25×8 | 1500 | 146 |
213/11 | 202/13.2 | 192/15.8 | 2000 | 179 | ||||||
292/6.0 | 277/7.2 | 263/8.6 | 2500 | 213 | ||||||
372/6.0 | 353/4.6 | 335/5.4 | 3000 | 246 | ||||||
350 | 58/366 | 107/40 | 55/402 | 102/44 | 52/442 | 96/48 | 1263 | 77×8 | 1500 | 171 |
178/16 | 169/18 | 161/22 | 2000 | 2088 | ||||||
250/8.5 | 237/10 | 226/12 | 2500 | 245 | ||||||
322/5.3 | 306/6.9 | 290/9.6 | 3000 | 282 | ||||||
400 | 57/415 | 92/58 | 54/48 | 87/63 | 51/492 | 83/69 | 1612 | 26×8 | 1500 | 192 |
154/23 | 142/25 | 135/27 | 2000 | 235 | ||||||
215/12 | 204/13 | 196/15 | 2500 | 278 | ||||||
278/7.7 | 264/9 | 250/11 | 3000 | 321 | ||||||
450 | 55/415 | 81/80 | 52/456 | 77/88 | 49/484 | 73/96 | 1995 | 78×8 | 1500 | 218 |
135/32 | 128/35 | 122/38 | 2000 | 268 | ||||||
189/17 | 180/19 | 171/21 | 2500 | 319 | ||||||
243/11 | 230/12 | 218/13 | 3000 | 370 | ||||||
500 | 90/746 | 36/241 | 72/895 | 32/260 | 58/984 | 29/281 | 2625 | 29×10 | 1400 | 535 |
68/89 | 62/96 | 56/104 | 1700 | 581 | ||||||
102/42 | 92/45 | 83/49 | 2000 | 627 | ||||||
126/28 | 113/30 | 102/32 | 2200 | 658 | ||||||
166/18 | 149/19 | 134/21 | 2500 | 704 | ||||||
198/12 | 178/13 | 160/14 | 2800 | 750 | ||||||
600 | 94/820 | 42/208 | 85/886 | 38/224 | 75/948 | 34/242 | 3590 | 30×10 | 1500 | 648 |
71/102 | 64/110 | 58/118 | 1800 | 702 | ||||||
106/47 | 95/51 | 86/55 | 2200 | 775 | ||||||
135/30 | 121/32 | 111/35 | 2500 | 830 | ||||||
168/21 | 156/23 | 141/25 | 2800 | 884 | ||||||
199/14 | 183/15 | 168/17 | 3200 | 957 | ||||||
